(R,R)-DACH-DNB

– 9 columns

Vendor: RegisTechnologies

Pirkle-type Chiral Column

The innovative DACH-DNB CSP was designed by Italian chemist, Professor Francesco Gasparrini, at Rome University La Sapienza. The DACH-DNB CSP, which contains the 3,5-dinitrobenzoyl derivative of 1,2-diaminocyclohexane, has been found to resolve a broad range of racemate classes including amides, alcohols, esters, ketones, acids, sulfoxides, phosphine oxides, selenoxides, phosphonates, thiophosphineoxide, phosphineselenide, phosphine-borane, beta-lactams, organometallics, atropisomers and heterocycles.

1 / 1

Select an image to enlarge and zoom.

Brand specifications

Every parameter recorded for every column in this Brand is shown here. A single value applies across the Brand; multiple values show what is recorded across its columns.

Mode	Chiral	pH stability from	2.5
Modification	Chiral	pH stability to	7.5
Pore Size (Å)	100

Choose column specifications

Length Available: 250 – 500 mm

Internal Diameter Available: 4.6 – 50 mm

Particle Size Available: 5 – 10 μm

Pore Size Recorded value 100 Å

Columns in this brand

9 columns shown


1-788101-300	250	4.6	5.0	100
1-788102-300	250	10.0	5.0	100
1-788103-300	250	21.1	10.0	100
1-788104-300	250	30.0	5.0	100
1-788400-300	250	4.6	10.0	100
1-788707-300	250	30.0	10.0	100
1-788708-300	250	50.0	10.0	100
1-788709-300	500	50.0	10.0	100
1-788712-300	500	30.0	10.0	100
