Product no. 219TP5105
Get quote
Catalog Vydac TP Diphenyl 219TP5105

Select an image to enlarge and zoom.

219TP5105 images

Zoom in to see detail, then drag or scroll. Press Escape to close.

Price / Quotation
Price on request

Vydac TP Diphenyl

by GRACE

Vydac® TP Columns

The Industry Standard for Polypeptide Separations

  • Exceptionally long column lifetime and negligible phase leaching
  • Reliable protein purifications, scalable from analytical to preparative scale
  • Surface area 60-110 (m2/g)



The 300Å pores of TP silica provides polypeptides complete access to the interior of the silica. The unique process by which we manufacture Vydac® TP silica results in high purity with carefully controlled characteristics. It is the standard that has defined large pore HPLC silica for polypeptide separations for nearly two decades.

Lowest capacity first generation diphenyl media. Polypeptides with aromatic side chains, large hydrophobic proteins, membrane-spanning peptides, lipid peptides, fusion proteins from inclusion bodies.

Specification

View this column family
Vendor GRACE Internal Diameter 1
Brand Vydac TP Diphenyl Pore size 300
Modifification Silica/Diphenyl Surface Area 60-110
Mode Reversed-Phase Carbon Load, % 4
Particle Size 5 Endcapped Yes
Length 50

Product Usage

Bio-molecules Large molecules Peptides Proteins

Applications of column use

No Applications are assigned to this Product.

Similar columns from other manufacturers to Vydac TP Diphenyl

Specific columns from up to 10 families from other manufacturers with the same Mode and Modification. Compare a column to see its recorded specifications alongside this column.

How similarity is calculated
The percentage compares the two specific columns shown, using Modification (25%), Product Usage (20%), Carbon Load (15%), Endcapping (10%), Pore Size (10%), Surface Area (8%), pH Stability (8%) and Particle Size (4%). Missing values are excluded. At least three criteria and 50% of the total weight must be available to show a score. Open Compare Column for every contribution and the calculation. Mode is a required discovery filter; length and internal diameter do not affect the score. Recommendations retain the family discovery rules. An eligible sponsor may appear first and is labelled Sponsored.
A similarity score does not guarantee identical selectivity or performance. Confirm suitability under the intended method conditions.
Viva
by RESTEK
P/N 9516531
80% similarity
ModeReversed-Phase
ModificationSilica/Diphenyl
Pore Size300
Shared Product UsageNo shared usage recorded
Agilent Pursuit
by Agilent Technologies
P/N A3040030X020
59% similarity
ModeReversed-Phase
ModificationSilica/Diphenyl
Pore Size180
Shared Product UsageNo shared usage recorded
